WB5axH6-35 Wi-Fi 6 Outdoor Wireless Bridge, 33dBi Parabolic, 20KM+, SFP, IP67
WB5AXH6-35
5 Years Warranty
Specifications
| Type | Outdoor Long-Range PtP Wireless Bridge |
| Standard | Wi-Fi 6 (IEEE 802.11ax), 5GHz (5.150–5.850GHz) |
| Antenna | Built-in 33dBi Parabolic Dish |
| Max Speed | 2402Mbps PHY, 900+ Mbps actual PTP |
| Range | 20KM+ (LoS) |
| SFP | 1× Gigabit SFP |
| WAN | 1× Gigabit (PoE 802.3at) |
| LAN | 1× Gigabit |
| Power | DC 12V/1A or PoE 802.3at |
| Power Consumption | <10W |
| Enclosure | IP67 Metal |
| Dimensions | 218 × 243 × 64 mm |
| Weight | 1.74 kg |
| Temperature | -40°C ~ +70°C |
Features
- Wi-Fi 6 (802.11ax) with 2402Mbps PHY rate and 900+ Mbps actual PTP throughput
- Built-in 33dBi parabolic dish for 20KM+ ultra-long-range point-to-point links
- Gigabit SFP fiber port for hybrid copper+fiber backhaul network topologies
- IP67 metal enclosure rated -40°C to +70°C for extreme industrial environments
- TDMA intelligent polling, ATPC, and automatic channel selection
- VPN tunneling (IPSec/PPTP/L2TP) and VLAN transparent transmission
- Cloud, HTTP GUI, SSH, SNMP, QoS, and WNMS remote management
The WB5axH6-35 is a professional Wi-Fi 6 outdoor wireless bridge with a built-in 33dBi parabolic dish antenna for 20KM+ ultra-long-range point-to-point links. Delivering 2402Mbps PHY rate and 900+ Mbps actual throughput with TDMA intelligent polling, ATPC, Gigabit SFP fiber port, VPN tunneling, VLAN, and IP67 metal enclosure rated to -40°C to +70°C, it is engineered for WISP and ISP backhaul, surveillance data transmission, rural broadband, and industrial networking over the most demanding long-distance links.
Ideal For
- Ultra-long-range PtP backhaul links for WISPs, ISPs, and rural broadband providers
- High-definition IP camera and CCTV video transmission over 10–20KM+
- Mining, oilfield, mountain-to-valley, and remote facility broadband connectivity
- Secure site-to-site VPN backhaul links for industrial SCADA and enterprise networks
- Rural village and island broadband delivery requiring maximum link budget
Deployment Advantages
The 33dBi parabolic dish provides the highest gain in the WB5axH6 series, delivering superior link budget for the longest PtP distances where link margin is most critical. Wi-Fi 6’s OFDMA and MU-MIMO capabilities provide significantly higher actual throughput than 802.11ac platforms at equivalent antenna gain, enabling aggregation of multiple HD IP camera streams or high-bandwidth enterprise data links over a single PtP connection.
The Gigabit SFP port enables hybrid fiber+wireless topologies — connecting a fiber backbone at a tower to a wireless link reaching a remote building — without requiring a separate media converter. VPN support (IPSec/PPTP/L2TP) encrypts all traffic for secure industrial and enterprise deployments at -40°C to +70°C operating temperature extremes.
OEM/ODM Ready
MossLink offers OEM and ODM customization for this product including custom firmware, enclosure branding, private-label cloud management platforms, and custom packaging. Volume pricing is available for WISPs, ISPs, industrial integrators, and wireless equipment distributors. Contact us to discuss your project requirements.
