WR3005K Wi-Fi 6 AX3000 Gigabit Router, 6 Antennas, Industrial Protection

WR3005K

Standard Wi-Fi 6 (802.11ax)
Band Dual-Band (2.4GHz + 5GHz)
Max Speed AX3000 (574 + 2402 Mbps)
CPU MT7981B + MT7976 + MT7531, ARM Dual-Core 1.3GHz
RAM 512MB DDR
View all specifications →

5 Years Warranty

Talk via WhatsApp

Specifications

Standard Wi-Fi 6 (802.11ax)
Band Dual-Band (2.4GHz + 5GHz)
Max Speed AX3000 (574 + 2402 Mbps)
CPU MT7981B + MT7976 + MT7531, ARM Dual-Core 1.3GHz
RAM 512MB DDR
Flash 128MB
Antenna 6× 5dBi External (2×2.4G + 4×5G)
Ethernet 1× GbE WAN + 3× GbE LAN (HNAT 2Gbps)
Max Clients 128
Surge Protection 6kV (Common Mode) / 1.5kV (Differential Mode)
Dimensions 208.6 × 129.5 × 40.6 mm
Temperature -10°C ~ +45°C
Power DC 12V / 1A

Features

  • Wi-Fi 6 AX3000 on MTK MT7981B Dual-Core 1.3GHz enterprise platform
  • Industrial-grade 6kV surge and EMI shielding protection
  • Six 5dBi external antennas — superior coverage vs. 4-antenna designs
  • Hardware NAT up to 2Gbps for high-speed wired forwarding
  • Supports up to 128 concurrent devices with OFDMA and MU-MIMO
  • Mesh and relay mode for multi-room and multi-floor deployments
  • WPA3, VPN client, guest WiFi, firewall, and TR069 management
  • 512MB DDR RAM / 128MB Flash for stable high-load operation

The WR3005K is a dual-band Wi-Fi 6 AX3000 gigabit router with industrial-grade 6kV surge protection, six 5dBi external antennas, and the MTK MT7981B ARM Dual-Core 1.3GHz platform with 512MB RAM. Supporting 128 concurrent clients, Mesh networking, VPN, and TR069 management, it is engineered for ISPs, hospitality networks, offices, and enterprise environments requiring reliable, protected wireless infrastructure.

Ideal For

  • ISP customer premises equipment (CPE) requiring surge protection
  • Hotels, restaurants, and hospitality venue Wi-Fi networks
  • Small-to-medium enterprise office networks
  • Co-working spaces and educational institution networks
  • Environments with power fluctuations requiring industrial protection

Deployment Advantages

The 6kV surge protection distinguishes the WR3005K from consumer-grade routers, making it suitable for deployment in regions with unstable power grids, thunderstorm-prone areas, or industrial environments. EMI shielding further protects the device from electromagnetic interference common in manufacturing or commercial facilities.

Six external antennas — four on 5GHz and two on 2.4GHz — provide more spatial streams and coverage than standard four-antenna designs. Hardware NAT at 2Gbps ensures forwarding performance keeps pace with multi-gigabit WAN connections. TR069 protocol support enables ISPs to remotely provision, configure, and troubleshoot devices across large subscriber deployments.

OEM/ODM Ready

MossLink offers OEM and ODM customization for this product, including custom firmware, ISP branding, TR069 server integration, surge protection specifications, and private-label packaging. Volume pricing is available for ISPs, telecom operators, and enterprise resellers. Contact us to discuss your project requirements.

Frequently Asked Questions

What industrial protection does the WR3005K provide?
The WR3005K includes carrier-grade 6kV common mode and 1.5kV differential mode surge protection, over-voltage and over-current safeguards, and EMI shielding. This level of protection is standard for telecom and ISP equipment deployed in environments with power fluctuations or lightning exposure.
How does the WR3005K perform in high-density environments?
With MU-MIMO, OFDMA, and 160MHz bandwidth support on the MTK MT7981B platform, the WR3005K efficiently manages up to 128 simultaneous client connections. Hardware NAT at 2Gbps ensures wired throughput is not a bottleneck in mixed wired and wireless deployments.
Is the WR3005K suitable for hotels and offices?
Yes. Mesh/relay support, TR069 remote management, WPA3 enterprise security, guest WiFi, and VPN client capability make the WR3005K well suited for hotels, co-working spaces, restaurants, and small-to-medium enterprise networks where reliability and manageability are required.
Is OEM/ODM customization available for this product?
Yes. MossLink offers full OEM and ODM services for this product, including custom firmware features, hardware modifications, enclosure branding, and private-label packaging. Minimum order quantities apply. Contact us to discuss your project requirements.
